Static Dissipative PVC Booties

Product Code: DY6002

产品查询
These booties have a three-piece construction of static dissipative polyester fabric, a PVC upper and a unique one piece molded static dissipative PVC sole.
This one-piece sole design allows human body static charges to dissipate via the insole to the ESD safe floor.

Features
  • Sizes : 220 - 300mm
  • RTG < 35MΩ
  • Single Piece Molded Sole
  • Excellent Electrical Properties
  • Non-Marking, Non-Slip Sole

    Specifications
    Fabric Surface Resistance
    (-GD, 5mm checked)
    Fabric Surface Resistance
    (-ST, 5mm parallel)

     105 to 106 Ω  105 to 1010 Ω


    Resistance of Shoes
    (ANSI/ESD STM9.1)
    Resistance to Ground
    (ANSI/ESD STM97.1)
    < 1.0 x 109 Ω
    (SD, Static Dissipative)
     < 3.5 x 107 Ω
    (SD, Static Dissipative)
